TDR Winged Roller Mower

The MAJOR TDR range leads the market in wide area mowers and is an exceptionally low-maintenance trailed rotary mower. It is available in 4.9m and 6.1m working widths.

The patented three point pivot system allows the machine to glide over the ground contours eliminating scalping of the grass. The blades are synchronised to rotate in opposite directions and overlap each other by 75mm to ensure a perfect finish every time.

In short grass this mower leaves a professional striped finish equivalent to that of a cylinder mower. The gear driven drive line allows this machine to easily cope with heavier conditions. The machines wings can be folded up to a 90° angle giving a transport width of 2.5m.

Features

Made in Ireland

Made by Major Equipment in Ireland, an Award-winning manufacturer of innovatively designed agricultural machinery and professional mowers. Major products are exported to over countries worldwide.

Front & Rear Rollers

Standard with an extra-heavy duty adjustable front and rear rollers

Simple Height Adjustment

Simple height adjustment mechanism, giving option of cutting heights between 10mm up to 100mm.

Unique Pivoting Frame

The TDR has a patented three point pivot system which allows the machine to glide over the ground contours eliminating scalping of the grass.

Synchronised Blades

The blades are synchronised to rotate in opposite directions and overlap each other by 75mm to ensure a perfect finish every time.

Multiple Decks

The wings can be operated independently, so you can have the wings up and be mowing with just the rear mowing deck or wings down and rear deck folded up.

2-in-1 Mower

The rear mower can be removed from the winged mower frame and can be operated by itself.

Major TDR Tri-Deck-Mower
Triple deck mower council parks fields (1)
MAJOR TDR16000 16m Groundcare Machinery
MAJOR TDR16000 Winged Trailed Tractor Mower
Triple deck mower council parks fields (2)

Specifications

TDR16000 TDR20000
Working Width
TDR16000 4.9m
TDR20000 6.1m
Transport Width
TDR16000 2.5m
TDR20000 2.5m
Tractor Power (HP)
TDR16000 65 - 100hp
TDR20000 75 - 120hp
PTO rpm
TDR16000 540
TDR20000 540
Cutting Height
TDR16000 10-150mm
TDR20000 10-150mm
Rotors
TDR16000 8
TDR20000 10
Blades
TDR16000 32
TDR20000 40
Weight
TDR16000 2260kg
TDR20000 2675kg
Blade Speed
TDR16000 76m/s
TDR20000 76m/s
Mowing Rates (Acres/hr at 7mph)
TDR16000 13.22
TDR20000 16.58
Measures and weights are approx. and non-binding.

Testimonials

"Flexibility"

“The flexibility of the Major TDR Roller means we don’t need lots of different mowers in our fleet. We can use the rear deck independently of the wings, which gives us additional flexibility.”

Bradford Decker, Contract Monitoring Officer, London Borough of Ealing
